机器型号 Machine Model
|
1092
|
1575
|
1760
|
2200
|
2500
|
2800
|
3000
|
3200
|
3500
|
|
宽度（mm） Width (mm)
|
1300
|
1800
|
2000
|
2200
|
2500
|
2800
|
3000
|
3200
|
3500
|
|
成品直径(mm) Finished Products Diameter
|
Φ 90～150 （松紧可调） (Tightness can be adjustable)
|
|
成品纸芯内径(mm) Finished Products Inner Diameter
|
Φ30～50 mm
|
|
原纸直径(mm) Jumbo roll diameter (mm)
|
Φ 1200(其它规格请指定) (Other sizes can be ordered)
|
|
原纸纸芯内径 Jumbo Roll Inner Diameter
|
3”，76.2 mm (其它规格请指定) (other sizes can be ordered)
|
|
打孔节距(mm) Perforation distance (mm)
|
4刀(blade)，90～160mm；2刀(blade)，180～320mm；
|
|
生产速度 Production speed
|
180～220米/分钟 m/min
|
|
参数设定 Parameter set
|
人机界面操作系统 Man-machine Interface Operation System
|
|
编程控制器 Programmable controller
|
PLC电脑编程 PLC program
|
|
机械传动 Mechanical driving
|
主机采用无级变速箱传动，确保成品总长精确
Driven by stepless speed-regulator to guarantee the precise length of final products.
|
|
压花装置 Embossment unit
|
单压花，双面压花，钢对钢压花 Single embossment, Double embossment, Steel to steel embossment; (客人选配)
|
|
压花底辊 Embossment down roller
|
毛布辊，羊毛辊，胶辊 Felt roller, paper roller, rubber roller
|
|
原纸架 Jumbo roll stand
|
1-3层（层数请指定） 1-3 plies (ply quantity can be ordered)
|
|
气动系统 Air pneumatic system
|
3匹空压机，最少压力5kg/cm2 Pa(客户自备)
3 Pa (air-compressor), the minimum pressure 5kg/cm2 pa (customers should be prepared by themselves)
|
|
动力 Power
|
变频调速5.5-22KW (Frequency speed-regulate )
|
|
外型尺寸(m)(L×W×H) Overall size
|
7 X (2.3 -4.5) X 1.8 M
|
|
机器重量 Weight of equipment
|
约4000～8000kg (approximately)
|
|
选配项（需订购）Chosen items (Should be ordered separately)
|
|
压花 Embossment
|
单压花，双面压花，钢对钢压花 Single embossment, double embossment, steel to steel embossment
|
|
压花底辊 Embossment down roller
|
毛布辊，羊毛辊，胶辊 Felt roller, paper roller, rubber roller
|
|
原纸架 Jumbo roll stand
|
1-3层; 1-3 plies
|
|
原纸架传动 Jumbo roll stand driving
|
变速机传动 Driven by variator
|
|
收卷装置 Rewinding unit
|
无芯装置 Non-core unit
|
|
印刷 Printing unit
|
单色胶版印刷 Single color heliotype printing unit
|
|
压边纹 Side rolling embossment
|
钢对钢 Steel to steel
|
|
打孔方式 Perforation mode
|
气动分离 Air pneumatic separating unit
|
|
压光 Smooth embossment
|
钢对钢, 钢对胶 Steel to steel, Steel to rubber ;
|
|
远程通讯服务系统 Remote telecom service system
|
需订购 Should be ordered separately.
|
