SRS50-HZA0-S01施克SICK编码器

克重：SRS50-HZA0-S01
规格： SRS50-HZA0-S01
单价： 0.00 元/
起订： 0
供货总量： 0
发货期限：自买家付款之日起 3天内发货
所在地：深圳市
有效期至：长期有效
最后更新：2015年03月27日
我要询价

公司基本资料信息

深圳市展控机电设备有限公司

联系人张小姐 ( 女士 )
会员 [加为商友] [发送信件]
邮件 ellazhang0907@163.com
电话 0755-86067680
手机 13077890028
地区
地址南山区科技园白石新村新塘二坊

产品详情

SRS50-HZA0-S01 Product features
Number of sine/cosine periods per revolution: 1,024
Type: SinCos
Version: Stand alone
Shaft version: Hollow shaft
Shaft diameter: 10, 12, 14 mm, 1/2", 3/8"
Model: Singleturn
EEprom: 2048 EEprom
Connection type: cable, 1.5 m
Interface: HIPERFACE
Diameter: 60 mm
=============================================================
SRS50,SRM50, SRS50 STANDALONE,SRM50,STANDALONE GENERATION
Motor feedback system with plug-in shaft and rubber support(Fig.1)
1. assembly
2. Pressing force required=250N-500N
3. disassembly
Motor feedback system with tapered shaft and spring mounting support(Fig.2)
1. assembly:tightening torque:3.1Nm
2. disassembly
Motor feedback system with tapered shaft and resolver style support(Fig.3)
1. assembly:tightening torque:3.1Nm
2. disassembly
Motor feedback system with tapered shaft and rubber support(Fig.4)
1.assembly:tightening torque:3.1Nm
2.disassembly
Motor feedback system with face mount flange(standalone) (Fig.5)
1.assembly
2.disassembly
Motor feedback system with servo mount flange(standalone) (Fig.5)
1.assembly
2.disassembly
