IME12-08NNSZC0S施克SICK接近开关

克重：IME12-08NNSZC0S
规格： IME12-08NNSZC0S
单价： 0.00 元/
起订： 0
供货总量： 0
发货期限：自买家付款之日起 3天内发货
所在地：深圳市
有效期至：长期有效
最后更新：2015年03月27日
我要询价

公司基本资料信息

深圳市展控机电设备有限公司

联系人张小姐 ( 女士 )
会员 [加为商友] [发送信件]
邮件 ellazhang0907@163.com
电话 0755-86067680
手机 13077890028
地区
地址南山区科技园白石新村新塘二坊

产品详情

施克sick直流两线电感式接近传感器IM12
产品技术简介:
在鑫属中安装，齐平式或非齐平式.。
常开/常闭输出。
短路保护（脉冲式）。
坚固黄铜，镀镍外壳，带m12x1mm细螺纹。
电缆或插头。
防护等级ip67。
led状态指示灯3600。
SICK IME12-08NNSZC0S Overview
IME12-08NNSZC0S Inductive proximity sensor IME-series advanced sn 8mm, non flush, connector M12 DC 3-wire, NPN, NO

SICK IME12-08NNSZC0S Description
Features
Sensing range Sn: 8 mm
Installation in metal: Non-flush
Switching frequency: 2,000 Hz
Connection type: Connector M12, 4-pin
Switching output: NPN
Output function: NO
Electrical wiring: DC 3-wire
Enclosure rating: IP 67 1)
Switching mode: NO
1) According to EN60529
Mechanics/electronics
Design: cylindrical
Housing length: 65 mm
Supply voltage: 10 V DC ... 30 V DC
Residual ripple: ≤ 10 %
Power consumption: ≤ 10 mA 1)
Voltage drop: ≤ 2 V
Continuous current Ia: ≤ 200 mA
Hysteresis: 5 % ... 15 %
Repeatability: ≤ 2 % 2) 3)
Temperature drift (of sr):: ± 10 %
EMC: According to EN 60947-5-2
Reverse polarity protection:
Short-circuit protection:
Housing material: Metal, Nickel-plated brass
Housing cap: Plastic, PA6
Power-up pulse suppression:
Time delay before availability: ≤ 100 ms
Ambient temperature, operation: -25 °C ... 75 °C
Shock/vibration stress: 30 g, 11 ms/10 ... 55 Hz, 1 mm
Max. tightening torque: 12 Nm
Thread size: M12 x 1
Thread lenght: 43 mm
1) Without load 2) Ub and Ta constant 3) Of Sr
